How to Install Lippert Electric Tongue Jack: Step-by-Step Guide

Are you tired of manually cranking your trailer’s tongue jack up and down every time you hitch or unhitch your trailer? Look no further! In this step-by-step guide, we will show you how to easily install a Lippert electric tongue jack for smoother, hassle-free towing experiences. Say goodbye to hand cramps and sore muscles, and say hello to convenience and ease with our straightforward installation process. Let’s get started!

Introduction

Installing a Lippert Electric Tongue Jack is a straightforward process that can be completed in just a few simple steps. Before you begin, make sure you have all the necessary tools and materials on hand:

• Lippert Electric Tongue Jack
• Drill with appropriate bits
• Screws and washers
• Wiring harness kit
• Safety glasses

To start, park your trailer on a level surface and disconnect it from the tow vehicle. Lower the manual tongue jack so there is no weight on it, then remove it by unscrewing the bolts that hold it in place. Next, position the Lippert Electric Tongue Jack in the same spot and secure it using the provided screws and washers.

Once the jack is securely attached, you can begin wiring it to your trailer’s electrical system. Follow the instructions in the wiring harness kit carefully, making sure to connect the positive and negative wires correctly. Once the jack is wired up, test it to ensure it is functioning properly before hitching the trailer back up to your tow vehicle.

Gathering Necessary Tools and Materials

When preparing to install your Lippert Electric Tongue Jack, it is essential to gather all the necessary tools and materials beforehand to ensure a smooth and efficient installation process. Having everything you need on hand will help you avoid unnecessary delays and interruptions during the installation.

Tools and Materials Needed:

• Lippert Electric Tongue Jack kit
• Power drill
• Drill bits
• Socket wrench set
• Screwdriver set
• Electrical tape
• Wire cutters/strippers
• Level
• Silicone sealant
• Safety goggles
• Work gloves
• Step ladder

Before starting the installation process, double-check that you have all the tools and materials listed above readily available. This will help you stay organized and focused throughout the installation. Proper preparation is key to a successful installation of your Lippert Electric Tongue Jack.

Preparing the Trailer

To prepare the trailer for installing the Lippert Electric Tongue Jack, you first need to make sure the trailer is parked on a level surface to ensure stability during the installation process. It’s also important to disconnect the trailer from the tow vehicle and securely place wheel chocks behind the trailer wheels to prevent any movement.

Next, gather all the necessary tools and equipment for the installation, including a power drill, wrench set, and any additional hardware that may be required. It’s a good idea to lay out all the components of the electric tongue jack and familiarize yourself with the instructions before starting.

Before beginning the installation, ensure that the trailer’s battery is fully charged to power the electric tongue jack. You may need to consult the trailer’s manual to locate the battery and determine the best way to access it. Once everything is in place, you can proceed with the step-by-step installation process to ensure a smooth and successful outcome.

Installing the Lippert Electric Tongue Jack

<p>Next, locate the existing manual tongue jack on your trailer and remove it carefully by loosening the bolts or screws that hold it in place.</p>



<p>Once the old tongue jack is removed, position the Lippert Electric Tongue Jack in its place, ensuring it is aligned properly. Secure it by tightening the bolts or screws.</p>



<p>Finally, connect the wiring according to the manufacturer's instructions, testing the electric tongue jack to ensure it is functioning correctly.</p>

Connecting the Wiring

To connect the wiring for your Lippert Electric Tongue Jack, follow these simple steps:

• Locate the wiring harness on the back of the tongue jack.
• Identify the positive (usually red) and negative (usually black) wires.
• Strip the ends of the wires to expose the copper underneath.
• Connect the positive wire to the positive terminal and the negative wire to the negative terminal.

Make sure to secure the connections properly to avoid any loose wiring that could lead to malfunction. Once the wiring is connected, you can test the electric tongue jack to ensure that it is working correctly. If everything is in order, you are now ready to enjoy the convenience of your newly installed Lippert Electric Tongue Jack.

Attaching the Foot Pad

To attach the foot pad to the Lippert Electric Tongue Jack, follow these simple steps:

• Start by locating the foot pad and ensuring that it is the correct size for your jack.
• Slide the foot pad onto the bottom of the jack, making sure it is secure and properly aligned.
• Tighten the bolts or screws on the foot pad to securely fasten it to the jack.
• Make sure the foot pad is level and stable before using the jack to prevent any accidents or damage.

By following these steps, you can easily attach the foot pad to your Lippert Electric Tongue Jack and ensure safe and efficient operation.

Testing the Jack for Proper Functioning

To ensure that your Lippert Electric Tongue Jack is properly functioning, it is important to conduct a series of tests after installation. This will help you avoid any potential issues down the line and ensure the safety and efficiency of your RV setup. Below are the steps you can take to test the jack for proper functioning:

• Power Connection Test: Start by making sure that the power source is properly connected to the jack. Check the connection at both ends to ensure there are no loose wires or faulty connections.
• Manual Override Test: Test the manual override function of the jack by disconnecting the power source and using the manual crank to raise and lower the jack. This will ensure that you have a backup in case of power failure.
• Load Capacity Test: Place a suitable load on the jack (such as your RV trailer) and test its lifting and lowering capabilities. Make sure that the jack can handle the weight without any issues.

If the jack passes all of these tests, then you can be confident that it is functioning properly and is ready for use. If you encounter any issues during testing, refer to the user manual for troubleshooting tips or contact customer support for assistance. By following these steps, you can ensure that your Lippert Electric Tongue Jack is operating safely and efficiently.

Securing the Jack in Place

Once the Lippert Electric Tongue Jack is properly installed on your RV, it’s important to secure it in place to ensure stability and safety while traveling. Follow these simple steps to secure the jack:

• Make sure the jack is fully retracted before securing it in place.
• Use the provided locking pin to lock the jack in position.
• Check that the jack is securely locked in place by gently trying to move it.
• For added security, you can also use a locking hitch pin or padlock to prevent tampering.

By following these steps, you can rest assured that your Lippert Electric Tongue Jack is securely in place and ready for your next adventure on the road!

Adjusting Height Settings

To adjust the height settings of your Lippert Electric Tongue Jack, follow these simple steps:

• Locate the height adjustment switch on the side of the jack.
• Using the switch, raise or lower the jack to your desired height. The jack can typically adjust from 18 inches to 28 inches, giving you plenty of flexibility for different towing setups.
• Make sure the jack is securely in place before hitching or unhitching your trailer.

If you need to fine-tune the height settings, you can also manually adjust the jack using the provided crank handle. Simply insert the handle into the manual override slot and turn it clockwise or counterclockwise to raise or lower the jack.

With these simple steps, you can easily adjust the height settings of your Lippert Electric Tongue Jack to ensure smooth and efficient towing every time.

Regular Maintenance Tips

Regular maintenance of your Lippert Electric Tongue Jack is crucial to ensure its longevity and smooth operation. Here are some key tips to help you keep your tongue jack in top condition:

• Clean regularly: Dust and dirt can build up on the exterior of your tongue jack, leading to potential damage. Use a mild soap and water solution to clean the jack regularly.
• Lubricate moving parts: Applying a silicone spray lubricant to the moving parts of the jack will help to prevent corrosion and ensure smooth operation.
• Inspect for wear and tear: Check the jack for any signs of wear, such as cracks or rust. Replace any damaged parts promptly to prevent further issues.

Further Troubleshooting Steps

If you have followed the previous steps and still encounter issues with your Lippert Electric Tongue Jack, don’t worry! There are you can take to ensure a successful installation.

1. **Check the power source:** Make sure the power source you are using is adequate for the electric tongue jack. Check the battery or power outlet to ensure it is providing enough power for the jack to operate.

2. **Inspect the wiring:** Check the wiring connections to make sure they are secure and free of any damage. Loose or damaged wires can prevent the jack from functioning properly.

3. **Reset the jack:** If the jack is not responding to the controls, try resetting it by disconnecting the power source for a few minutes and then reconnecting it. This can sometimes resolve any issues with the jack’s internal system.

4. **Contact customer support:** If you have tried all of the above steps and are still experiencing problems, it may be time to contact Lippert’s customer support for further assistance. They can provide additional guidance and troubleshooting tips to help you get your electric tongue jack up and running smoothly.

By following these , you can overcome any challenges you may face during the installation process and ensure that your Lippert Electric Tongue Jack is working as intended.

To Wrap It Up

In conclusion, installing a Lippert electric tongue jack is a straightforward process that can greatly simplify your RV setup and breakdown routine. By following the step-by-step guide provided in this article, you can ensure a smooth and successful installation. Remember to always prioritize safety and consult the manufacturer’s manual for any specific instructions. With your new electric tongue jack in place, you’ll be ready to hit the road with ease and convenience. Happy camping!
